Factory Direct Hot Metal Roof Tile Standing Seam Roll Forming Machine

Our PLC controlled roll formers are capable of producing precision standing seam tiles at speeds of up to 18 meters per minute with a tolerance of ±0.5mm (laser verified), machining 0.3-0.8mm steel/aluminum using 12-14 stations of 45 gauge forged steel rollers, reducing rework costs for residential and commercial roofing contractors by 40%.

Machine Video

Machine Specification

Product name	Standing Seam Roll Forming Machine
Main motor power	4kW/5.5KW/7.5KW or as actual demands
Hydraulic motor power	3kW/4KW.5.5KW or as actual demands
Voltage	380V/ 3 phase/ 50 Hz (or as your requirements)
Control system	Automatic PLC control system
Feeding thickness	0.4-0.5mm
Cutting method	Hydraulic cutting

Machine Features

The Working Flow

Manual uncoiler—feeding device—rolling form—speed, length, pieces set by PLC—hydraulic mold post cutting—collection table

Packaging Type Of Bag

Machine Function

Feeding table

Adopt adjustable round wheel design.

Small error good operation.

Control system

Programmable setting of profile length and quantity, Computed mode has two modes: automatic and manual one.

Forming system

Material of the roller: High grade No.45 forged steel

Roller station: 12-14 rows

Thickness of feeding material: 0.3-0.8mm

Cutting system

Electric type guillotine.
Knife made of steel.
Automatic activation.

Machine Option

Material Thickness: 0.3-0.8mm steel/aluminum (ASTM A653/B209)
Roller Durability: 12-14 45-gauge forged steel stations (20,000-hour lifespan)
Cutting System: Hydraulic guillotine cutter with ±0.1mm blade accuracy
Control: Siemens PLC with 10 profile presets

Machine Application
