Factory Direct Custom Metal Roofing Profile Standing Seam Roll Forming Machine

Designed for custom architectural projects, our 2025 roll-forming machine boasts a production speed of 18 m/min and can process steel and aluminum profiles with a thickness of 0.3-0.8 mm with an accuracy of ±0.5 mm. This machine supports CAD-based profile customization, translating architectural drawings into precise joints.

Machine Video

Machine Specification

Product name	Standing Seam Roll Forming Machine
Main motor power	4kW/5.5KW/7.5KW or as actual demands
Hydraulic motor power	3kW/4KW.5.5KW or as actual demands
Voltage	380V/ 3 phase/ 50 Hz (or as your requirements)
Control system	Automatic PLC control system
Feeding thickness	0.4-0.5mm
Cutting method	Hydraulic cutting

Machine Features

The Working Flow

Manual uncoiler—feeding device—rolling form—speed, length, pieces set by PLC—hydraulic mold post cutting—collection table

Packaging Type Of Bag

Machine Function

Feeding table

Adopt adjustable round wheel design.

Small error good operation.

Control system

Programmable setting of profile length and quantity, Computed mode has two modes: automatic and manual one.

Forming system

Material of the roller: High grade No.45 forged steel

Roller station: 12-14 rows

Thickness of feeding material: 0.3-0.8mm

Cutting system

Electric type guillotine.
Knife made of steel.
Automatic activation.

Machine Option

CAD-to-Profile in 72h: Upload .DWG/.DXF files → Receive sample panel
No-Minimum Order: Produce 1-10,000 linear meters per batch
Complex Geometry: Handles curves (R≥500mm), angles (15°-165°), and variable widths

Machine Application
