Factory Direct Self-Lock & Clip Lock Dual System Roof Roll Forming Machine | ±0.3mm

The machine complies with international standards and can produce self-locking and snap-lock seam panels for residential and commercial use with a tolerance of ±0.3 mm. Controlled by a Siemens PLC, it has an output speed of 25 m/min and can process titanium-zinc alloys with thicknesses ranging from 0.3 to 1.5 mm.

Machine Video

Machine Specification

Product name	Standing Seam Roll Forming Machine
Main motor power	4kW/5.5KW/7.5KW or as actual demands
Hydraulic motor power	3kW/4KW.5.5KW or as actual demands
Voltage	380V/ 3 phase/ 50 Hz (or as your requirements)
Control system	Automatic PLC control system
Feeding thickness	0.4-0.5mm
Cutting method	Hydraulic cutting

Machine Features

The Working Flow

Manual uncoiler—feeding device—rolling form—speed, length, pieces set by PLC—hydraulic mold post cutting—collection table

Packaging Type Of Bag

Machine Function

Feeding table

Adopt adjustable round wheel design.

Small error good operation.

Control system

Programmable setting of profile length and quantity, Computed mode has two modes: automatic and manual one.

Forming system

Material of the roller: High grade No.45 forged steel

Roller station: 12-14 rows

Thickness of feeding material: 0.3-0.8mm

Cutting system

Electric type guillotine.
Knife made of steel.
Automatic activation.

Machine Option

Self-locking/snag-locking dual-mode: Easy installation.
Anti-vibration structure: Stable structure.
Triple-drive inlet and outlet: Compensates for material fluctuations with an accuracy of ±0.05 mm.
Maximum output of 20 m/min: Single-shift production capacity ≥ 3,500 square meters.
Tungsten carbide roller: Surface hardness 72 HRA.
Hydraulic cutter: 5 million cuts with zero wear.

Machine Application
