Hot Sale Full Automatic Standing Seam Roof Tile Panel Sheet Making Cold Roll Forming Machine

This self-locking standing seam machine produces concealed fastener panels with vertical/trapezoidal legs.Featuring PLC-controlled 18m/min production and laser-verified ±0.5mm tolerance, it processes 0.3-0.8mm steel/aluminum via 14-station No.45 forged steel rollers with 20,000-hour lifespan. Validated in snow load applications with zero fastener failures.

Machine Video

Machine Specification

Product name	Standing Seam Roll Forming Machine
Main motor power	4kW/5.5KW/7.5KW or as actual demands
Hydraulic motor power	3kW/4KW.5.5KW or as actual demands
Voltage	380V/ 3 phase/ 50 Hz (or as your requirements)
Control system	Automatic PLC control system
Feeding thickness	0.4-0.5mm
Cutting method	Hydraulic cutting

Machine Features

The Working Flow

Manual uncoiler—feeding device—rolling form—speed, length, pieces set by PLC—hydraulic mold post cutting—collection table

Packaging Type Of Bag

Machine Function

Feeding table

Adopt adjustable round wheel design.

Small error good operation.

Control system

Programmable setting of profile length and quantity, Computed mode has two modes: automatic and manual one.

Forming system

Material of the roller: High grade No.45 forged steel

Roller station: 12-14 rows

Thickness of feeding material: 0.3-0.8mm

Cutting system

Electric type guillotine.
Knife made of steel.
Automatic activation.

Machine Option

Auto-Interlocking Seams: Eliminates manual clipping (reduces installation time 40%)
PLC-Guided Synchronization: Maintains ±0.5mm tolerance at full speed
Hydraulic Guillotine Cutting: ±0.1mm blade precision
48-Hour Global Support: On-site technician deployment

Machine Application
